VetMedix High Power Laser Therapy System

The VetMedix High Power Laser Therapy System provides veterinary professionals and equestrian centers with an advanced tool for equine rehabilitation and care. Developed by VetMedix (a specialist brand of FotonMedix) leveraging deep expertise in high-power laser technology, this system uses Photobiomodulation (PBM) to deliver targeted therapeutic effects.

It is designed to support treatment for a wide range of conditions by helping to reduce inflammation, alleviate pain, accelerate healing, and improve circulation, potentially serving as an effective alternative to painkillers and anti-inflammatory drugs in many cases.

Key Therapeutic Actions & Benefits

This system utilizes specific laser wavelengths and power to achieve physiological effects at the cellular level:

• Precision Anti-inflammatory: Modulates inflammatory pathways to help manage conditions like arthritis, tendinitis, bursitis, and post-traumatic edema.
• Rapid Analgesia: Aims to reduce pain quickly by influencing pain neurotransmitters and promoting muscle relaxation. Beneficial for joint/muscle pain, neuralgia, contusions, and fractures.
• Accelerated Tissue Healing: Promotes cellular energy (ATP) production, enhances metabolism, and supports ECM regeneration. Aids healing of wounds, ulcers, nerve/tissue injuries, speeds post-operative recovery, and helps prevent excessive scar tissue.
• Improved Microcirculation: Induces moderate vasodilation and repairs capillary networks, helping to reduce swelling and improve tissue oxygenation. Useful for contusions, hematomas, and edema.
• Enhanced Recovery: Helps relieve exercise fatigue and supports muscle endurance and recovery speed.

How It Works: Advanced Photobiomodulation (PBM)

VetMedix employs high-power laser PBM, delivering specific wavelengths of light energy deep into tissues (up to 15cm). This stimulates mitochondria in damaged cells, increasing ATP production and activating cellular repair and anti-inflammatory processes.

• Multi-Wavelength Approach (Model W5): Precisely selected wavelengths target different chromophores and depths for comprehensive treatment:
  • 650nm: Targets superficial tissues (skin/dermis) for wound healing and anti-inflammation.
  • 810nm: Penetrates deeply (skeletal/fascia) to promote ATP production.
  • 915nm: Targets fascia/muscle to increase cellular oxygen carrying capacity.
  • 940nm: Targets muscle/dermis to enhance oxygen supply and circulation in ischemic areas.
  • 980nm: Targets superficial tissues for rapid analgesic effects via photothermal interaction. (Adjust this section for the W2 model: Uses 650nm & 980nm)
• Balanced Power Control: Precisely controlled 30W output ensures therapeutic energy reaches target depth safely and effectively.
• Precision Optics: Self-developed optics ensure efficient energy delivery and treatment consistency.

System Specifications & Features

• Model: VetMedix3000W5
• Max Power: 30W
• Wavelengths: 650nm, 810nm, 915nm, 940nm, 980nm (Adjust for W2: 650nm, 980nm)
• Operation: Built-in treatment protocols and intuitive interface for ease of use.
• Technology: Advanced laser engine and optical modules developed in-house.
• Capability: Supports Laser Surgery Function Extension (details available upon request).

Standard Accessories Included

• Animal Laser Protective Eyewear (1 set)
• Laser Protective Eyewear for operator (2 pairs)
• Treatment Handpiece (1 pc)
• Standard Treatment Head (1 pc - specify which one, e.g., Len-01 or Len-02)
• (Optional items like Flight Case and other Treatment Heads can be listed separately)

Optional Treatment Heads

Expand versatility with specialized treatment heads (sold separately):

• Len-01 Small Non-contact: For smaller areas (<15cm), exposed wounds.
• Len-02 Large Non-contact: For larger areas (>15cm), exposed wounds.
• Len-04 Large Massage: Contact head for deeper muscle/tendon work.
• Len-05 Curved Light Guide: For pinpoint application (acupuncture points) or oral treatments.

Quality & Compliance

• Developed by: VetMedix / FotonMedix
• Supported by: Research from High Power Laser Medicine and Semiconductor Laboratory, Tsinghua Straits Research Institute (TSRI).
• Certifications: Manufactured under ISO 13485 quality management system. Complies with standards including IEC 60601-1, IEC 60601-1-2, IEC 60601-2-22, IEC 60825-1, RoHS. FDA QSR 820 compliant processes. (Confirm exact FDA status - e.g., "Registered Establishment" or specific device clearance if applicable).

Support & Training

• Built-in clinical protocols guide treatment application.
• Professional training resources available to ensure effective and safe implementation.
• Expert support from VetMedix.

Choose VetMedix for an advanced, non-invasive therapeutic tool to enhance your equine care services.
